What are the best Wireshark filters for OT cybersecurity monitoring and threat detection?

Quick answer: Wireshark display filters narrow OT captures by protocol, such as Modbus, DNP3 or Profinet, by device discovery and by suspicious behaviour like unexpected hosts or write commands. Capture passively, using a SPAN port or network TAP, and never actively scan fragile control systems. These filters help defenders map devices, audit protocols and spot abnormal traffic early.

Key takeaways

  • Use modbus, dnp3 or s7comm as display filters to isolate industrial traffic.
  • Flag Modbus write function codes from unknown hosts, since writes change process state.
  • Capture on a mirror port, never inline, in a live plant.

Table of Contents

In Operational Technology (OT), security is critical. From manufacturing plants to power grids, OT environments rely on specific industrial protocols like Modbus, DNP3, and Profinet to operate safely. But with growing cyber threats, network visibility has become more important than ever.

Wireshark, a free and open-source network protocol analyzer, offers powerful tools to monitor, analyze, and secure OT traffic. This post shows how to use Wireshark effectively for OT cybersecurity using practical filters and examples.

 What Is Wireshark and Why Is It For OT Networks?

Wireshark allows cybersecurity professionals to capture and analyze packets from OT network traffic. In industrial networks, it helps detect suspicious activities, troubleshoot communication issues, and audit protocol behavior in real-time.

OT environments often use non-IT protocols, so using Wireshark with OT-specific filters is essential to identify:

  • Broadcast storms

  • Unauthorized devices

  • Protocol misuse

  • Malicious commands (e.g., writing Modbus registers)

 Network Discovery Filters

Wireshark filters help identify devices and communication patterns in the network. Use these filters to discover unknown or unauthorized endpoints:

Use Case Wireshark Filter
Find broadcast traffic eth.dst == ff:ff:ff:ff:ff:ff
ARP responses (IP to MAC mapping) arp.opcode == 2
DHCP Discover/Request bootp.option.type == 53
Unique MAC addresses !(eth.addr in {00:00:00:00:00:00})
Unique IPs in a range ip.addr >= 192.168.0.0 and ip.addr <= 192.168.255.255

 Suspicious Activity Filters

Use these filters to detect malicious behavior such as scanning, tunneling, or malformed packets in OT networks:

Activity Wireshark Filter
Port scanning tcp.flags.syn == 1 && tcp.flags.ack == 0
Uncommon ports `tcp.dstport < 11
High order ports tcp.dstport > 1024
Modbus over non-standard ports modbus && tcp.port!= 502
Malformed packets `tcp.analysis.flags && (tcp.len == 0
Long TCP sessions for tunneling tcp.analysis.bytes_in_flight > 10000
OT devices communicating with Internet !(ip.dst >= 10.0.0.0 && ip.dst <= 10.255.255.255) &&!(ip.dst >= 172.16.0.0 && ip.dst <= 172.31.255.255) &&!(ip.dst >= 192.168.0.0 && ip.dst <= 192.168.255.255)

 General Utility Filters for OT Engineers

These filters help you isolate traffic by IP, MAC, stream, or port, especially useful during incident response or traffic audits:

Use Case Wireshark Filter
Follow Modbus stream tcp.stream eq
Filter by IP ip.addr ==
Filter by MAC address eth.addr ==
Conversations by port tcp.port ==

 Modbus Protocol Filters

Modbus is one of the most commonly used protocols in industrial control systems. Use these filters to track Modbus activity:

Filter Purpose Wireshark Filter
Show Modbus traffic modbus
TCP port 502 traffic tcp.port == 502
Write single coil modbus.func_code == 5
Write multiple registers modbus.func_code == 16
Device identification modbus.func_code == 43

 Filters for Other OT/ICS Protocols

OT networks may use a range of protocols depending on the vendor. Here are key filters:

Protocol Wireshark Filter
S7 (Siemens) tcp.port == 102 / s7comm
DNP3 tcp.port == 20000 / dnp3
EtherNet/IP tcp.port == 44818 / enip
Profinet eth.type == 0x8892
BACnet/IP udp.port == 47808 / bacnet

 Why Use These Filters for Cybersecurity?

Cyberattacks on industrial environments often mimic normal behavior. With Wireshark filters, you can:

  • Detect command injections

  • Identify unauthorized engineering stations

  • Spot traffic going to the public internet

  • Audit device configurations

  • Visualize attack patterns using packet coloring and follow streams

Best Practices for Using Wireshark in OT Environments

Practice Tip
Capture traffic during normal operations Helps set a performance baseline
Use display filters for specific protocols Avoids overload from irrelevant data
Label known devices and IPs Easier to spot anomalies
Store PCAP files securely Packet captures may contain sensitive ICS commands
Integrate with IDS tools Use Wireshark in combination with Suricata or Snort for deeper analysis

Conclusion

Wireshark is a powerful asset for OT cybersecurity professionals. Whether you’re tracking Modbus write operations or spotting unusual TCP sessions, using the right filters can mean the difference between a secure system and a compromised one.

With these ready-to-use display filters, you’ll be better equipped to monitor, investigate, and respond to threats in industrial control environments.

To take this further with guided labs and an instructor, see our hands-on network defence labs.

Related reading

Reference

For the authoritative details, see Wireshark documentation.

Frequently Asked Questions

Wireshark helps monitor, analyze, and troubleshoot OT network traffic to detect threats and ensure secure operations in ICS environments.

Yes, Wireshark includes built-in support for Modbus and can decode Modbus functions like reading registers or writing coils.

Use modbus.func_code == 5 for single coil writes or modbus.func_code == 16 for multiple register writes.

Use the filter tcp.flags.syn == 1 && tcp.flags.ack == 0 to identify potential scanning attempts.

Use modbus to display all captured Modbus protocol communications.

Yes, you can use filters like tcp.port == 102 / s7comm for S7 or tcp.port == 20000 / dnp3 for DNP3.

Use arp.opcode == 2 to display ARP responses mapping IPs to MAC addresses.

Use bootp.option.type == 53 to see DHCP Discover or Request packets.

Use tcp.analysis.flags && (tcp.len == 0 || ip.len < 20) to detect malformed packets.

It should be used in passive mode (no packet injection) and preferably with mirrored traffic for safety.

Use tcp.stream eq to follow a Modbus session from start to finish.

Yes, use tcp.analysis.bytes_in_flight > 10000 to spot long sessions used for tunneling.

Use: !(ip.dst >= 10.0.0.0 && ip.dst <= 10.255.255.255) && !(ip.dst >= 172.16.0.0 && ip.dst <= 172.31.255.255) && !(ip.dst >= 192.168.0.0 && ip.dst <= 192.168.255.255).

Use tcp.port == 44818 / enip to capture EtherNet/IP protocol traffic.

Use tcp.port == 502 to analyze Modbus TCP traffic.

Yes, use eth.type == 0x8892 to filter for Profinet traffic.

Use ip.addr == to isolate traffic from or to a specific IP address.

Use tcp.port == to view all traffic using a specific port.

Use modbus && tcp.port!= 502 to detect unauthorized Modbus traffic.

Use udp.port == 47808 / bacnet for BACnet/IP monitoring.

Yes, use tcp.analysis.bytes_in_flight > 10000 to identify such sessions.

It supports Modbus, DNP3, S7comm, BACnet/IP, Profinet, and more.

Undetected packets can be part of malware payloads, lateral movement, or ICS disruption tactics.

Absolutely. It helps reconstruct packet-level details and timelines during forensic investigations.

Limit captures to specific protocols or addresses, and ensure PCAP files are securely stored.

Yes, it's often used in conjunction with IDS and logging to satisfy regulatory audit requirements.
